C++ WebSocket Deep Dive | Handshake, Frames, Ping/Pong, Errors, Production Patterns

이 글의 핵심

Deep dive for operators: why idle TCP dies in NATs, fixing 400 handshakes, capping frames, Safari+strand, exponential backoff reconnect, per-session write queues, metrics, and graceful shutdown.

Introduction: “My WebSocket keeps dropping”

Scenario 1: disconnect every ~30 seconds

// ❌ NAT / firewall evicts idle TCP flows
// If the client is silent for longer than the middlebox timer,
// routers may RST the socket.
ws_.async_read(buffer_,  {
    // ec == connection_reset or connection_aborted
});

Why? NATs and firewalls track sessions and reap idle TCP entries. WebSocket can be quiet for a long time while still logically “open,” so the path looks dead. Mitigation: send Ping/Pong (or app-level keepalives) every 20–30s—shorter than the smallest idle timeout on the path.

Scenario 2: HTTP 400 on handshake

// ❌ Server returns 400 Bad Request
ws_.async_handshake(host, "/chat",
     {
        // ec == bad_request
        // server log: "Missing Sec-WebSocket-Key"
    });

Causes: missing Sec-WebSocket-Key, bad Upgrade, wrong version—anything that violates RFC 6455.

Scenario 3: huge messages exhaust RAM

// ❌ Accepting a 100 MiB frame blows the buffer
ws_.async_read(buffer_,  {
    // bytes == 100 * 1024 * 1024
});

Mitigation: always set read_message_max. Beast defaults are generous; tune per workload.

More scenarios

Scenario 4: Safari/Chrome WSS flakiness

If multiple threads touch the same websocket::stream without a strand, some browsers drop TLS WebSocket sessions randomly—serialize operations. Scenario 5: reconnect storms

Immediate reconnect loops hammer the server. Use exponential backoff and jitter. Scenario 6: broadcast write storms

Calling async_write for thousands of sessions at once floods the executor—use per-session queues and backpressure. Goals:

  • Byte-level handshake understanding
  • Frames with concrete Text/Binary/Ping/Pong/Close examples
  • Full heartbeat design
  • Error catalog with fixes
  • Best practices: reconnect, backpressure, strands
  • Production: metrics, graceful shutdown Prerequisites: Boost.Beast 1.70+, C++17.

Mental model

Treat sockets as addresses and async I/O as scheduled delivery—strands keep a single connection’s handlers ordered.

Ops-focused: these patterns come from production C++ services, not toy echo servers.

Contents

  1. Handshake deep dive
  2. Frames with worked examples
  3. Ping/Pong heartbeat
  4. Beast end-to-end examples
  5. Common errors
  6. Best practices
  7. Production patterns
  8. Checklist

1. Handshake anatomy

HTTP upgrade request (client → server)

Every WebSocket begins as an HTTP Upgrade request. Example aligned with RFC 6455:

GET /chat HTTP/1.1
Host: example.com:8080
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==
Sec-WebSocket-Version: 13
Origin: https://example.com

Header cheat sheet:

HeaderRequiredNotes
Upgrade: websocket✅Request protocol switch
Connection: Upgrade✅HTTP upgrade hop
Sec-WebSocket-Key✅16 random bytes → Base64 (mitigates proxy cache tricks)
Sec-WebSocket-Version: 13✅Only standardized version
OriginRecommendedBrowser CORS checks
Sec-WebSocket-ProtocolOptionalNegotiate subprotocols (chat, json, …)

Generating Sec-WebSocket-Key

#include <random>
#include <boost/beast/core/detail/base64.hpp>
// RFC 6455: 16 random bytes → Base64
std::string generate_websocket_key() {
    std::random_device rd;
    std::mt19937 gen(rd());
    std::uniform_int_distribution<> dis(0, 255);

    unsigned char key[16];
    for (int i = 0; i < 16; ++i) {
        key[i] = static_cast<unsigned char>(dis(gen));
    }

    std::string result;
    result.resize(boost::beast::detail::base64::encoded_size(16));
    result.resize(boost::beast::detail::base64::encode(
        &result[0], key, 16));

    return result;
}

Server response (101 Switching Protocols)

HTTP/1.1 101 Switching Protocols
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Accept: s3pPLMBiTxaQ9kYGzzhZRbK+xOo=

Computing Sec-WebSocket-Accept

#include <openssl/sha.h>
#include <boost/beast/core/detail/base64.hpp>
std::string compute_accept(const std::string& key) {
    const std::string magic = "258EAFA5-E914-47DA-95CA-C5AB0DC85B11";
    std::string input = key + magic;

    unsigned char hash[SHA_DIGEST_LENGTH];
    SHA1(reinterpret_cast<const unsigned char*>(input.data()),
         input.size(), hash);

    std::string result;
    result.resize(boost::beast::detail::base64::encoded_size(SHA_DIGEST_LENGTH));
    result.resize(boost::beast::detail::base64::encode(
        &result[0], hash, SHA_DIGEST_LENGTH));

    return result;
}

Algorithm: SHA1(Sec-WebSocket-Key + "258EAFA5-E914-47DA-95CA-C5AB0DC85B11") → Base64

Handshake sequence

sequenceDiagram
    participant C as Client
    participant S as Server

    C->>S: TCP connect
    C->>S: HTTP GET + Upgrade + Sec-WebSocket-Key
    S->>S: Validate key, compute Accept
    S->>C: HTTP 101 + Sec-WebSocket-Accept
    Note over C,S: WebSocket established
    C->>S: WebSocket frames
    S->>C: WebSocket frames

Handshake failure modes

StatusTypical cause
400 Bad RequestMissing Sec-WebSocket-Key, bad Upgrade
403 ForbiddenOrigin check failed
426 Upgrade RequiredWrong Sec-WebSocket-Version
503 Service Unavailableoverload / connection cap

2. Frames with worked examples

Frame layout (RFC 6455)

graph LR
    subgraph Header
        A[FIN 1bit] --> B[RSV 3bit]
        B --> C[Opcode 4bit]
        C --> D[Mask 1bit]
        D --> E[Payload Len 7bit]
    end
    E --> F[Extended 0/2/8 byte]
    F --> G[Mask Key 0/4 byte]
    G --> H[Payload Data]

Opcode reference

OpcodeValueMeaningDirection
Continuation0x0Continues previous fragmentBoth
Text0x1UTF-8 textBoth
Binary0x2Binary payloadBoth
Close0x8Close connectionBoth
Ping0x9Heartbeat probeBoth
Pong0xAHeartbeat replyBoth

Text frame (masked client → server)

Client → server: “Hello” (5 bytes)

Byte 0: 0x81 (FIN=1, Opcode=0x1 Text)
Byte 1: 0x85 (Mask=1, Payload Len=5)
Bytes 2-5: Masking Key (4 random bytes)
Bytes 6-10: "Hello" XOR Masking Key
// Masking required for client → server
// Example
void mask_payload(uint8_t* data, size_t len, const uint8_t key[4]) {
    for (size_t i = 0; i < len; ++i) {
        data[i] ^= key[i % 4];
    }
}

Why mask: mitigates cache poisoning when broken intermediaries mis-classify traffic.

Ping frame

Byte 0: 0x89 (FIN=1, Opcode=0x9 Ping)
Byte 1: 0x00 (MASK=0 server→client, len=0)

If payload present, Pong echoes it.

Pong frame

Byte 0: 0x8A (FIN=1, Opcode=0xA Pong)
Byte 1: 0x00 (Payload Len=0)

Close frame

Byte 0: 0x88 (FIN=1, Opcode=0x8 Close)
Byte 1: 0x02 (Payload Len=2)
Bytes 2-3: close code (e.g. 1000 normal, 1001 going away, 1002 protocol error)
Bytes 4+: optional UTF-8 reason

Common close codes:

CodeMeaning
1000Normal Closure
1001Going away (server shutdown, etc.)
1002Protocol Error
1003Unsupported Data
1006Abnormal closure (no close frame)
1007Invalid payload (UTF-8)
1011Internal Error

Handling control frames in Beast

ws_.control_callback(
     {
        switch (kind) {
            case websocket::frame_type::ping:
                // Beast sends Pong automatically
                break;
            case websocket::frame_type::pong:
                // observe heartbeat reply
                break;
            case websocket::frame_type::close:
                // peer initiated close
                break;
        }
    });

3. Ping/Pong heartbeat

Ping/Pong sequence

sequenceDiagram
    participant C as Client
    participant S as Server

    loop Every 30s
        C->>S: Ping
        S->>C: Pong (auto)
    end

    Note over C: No Pong within 10s
    C->>C: Treat as dead → reconnect

Client: send Ping + Pong timeout

class WebSocketClientWithHeartbeat
    : public std::enable_shared_from_this<WebSocketClientWithHeartbeat> {
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;
    net::steady_timer ping_timer_;
    net::steady_timer pong_timeout_;
    bool pong_received_ = false;

public:
    explicit WebSocketClientWithHeartbeat(net::io_context& ioc)
        : ws_(net::make_strand(ioc)),
          ping_timer_(ws_.get_executor()),
          pong_timeout_(ws_.get_executor()) {}

    void start_heartbeat() {
        pong_received_ = true;
        schedule_ping();
    }

private:
    void schedule_ping() {
        ping_timer_.expires_after(std::chrono::seconds(30));
        ping_timer_.async_wait(
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) return;
                self->send_ping();
            });
    }

    void send_ping() {
        pong_received_ = false;
        pong_timeout_.expires_after(std::chrono::seconds(10));
        pong_timeout_.async_wait(
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) return;
                if (!self->pong_received_) {
                    std::cerr << "Pong timeout - reconnecting\n";
                    self->reconnect();
                    return;
                }
            });

        ws_.async_ping({},
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) {
                    std::cerr << "Ping failed: " << ec.message() << "\n";
                    return;
                }
                self->schedule_ping();
            });
    }

    void on_pong() {
        pong_received_ = true;
        pong_timeout_.cancel();
    }

    void reconnect() {
        // reconnect with exponential backoff
    }
};

Server: auto Pong to Ping

Beast answers Ping with Pong by default. Custom logging example:

ws_.control_callback(
    [self = shared_from_this()](
        websocket::frame_type kind, beast::string_view payload) {
        if (kind == websocket::frame_type::ping) {
            // Beast sends Pong automatically
            // manual: ws_.async_pong(payload);
        } else if (kind == websocket::frame_type::pong) {
            // client Pong after server-initiated Ping
            self->on_pong_received();
        }
    });

Server → client Ping (optional)

Servers may initiate Ping to verify the peer is still alive.

void server_send_ping() {
    ws_.async_ping("heartbeat",
        [self = shared_from_this()](beast::error_code ec) {
            if (ec) {
                // write failure ⇒ dead connection
                self->close_session();
            }
        });
}

4. Beast examples

Async client (handshake + read + ping)

#include <boost/beast.hpp>
#include <boost/asio.hpp>
#include <iostream>
namespace beast = boost::beast;
namespace websocket = beast::websocket;
namespace net = boost::asio;
using tcp = net::ip::tcp;
class CompleteWebSocketClient
    : public std::enable_shared_from_this<CompleteWebSocketClient> {
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;
    net::steady_timer ping_timer_;
    std::string host_;
    std::string path_;

public:
    explicit CompleteWebSocketClient(net::io_context& ioc)
        : ws_(net::make_strand(ioc)),
          ping_timer_(ws_.get_executor()) {}

    void connect(const std::string& host, const std::string& port,
                 const std::string& path = "/") {
        host_ = host;
        path_ = path;

        tcp::resolver resolver(ws_.get_executor());
        resolver.async_resolve(host, port,
            beast::bind_front_handler(&CompleteWebSocketClient::on_resolve,
                                     shared_from_this()));
    }

private:
    void on_resolve(beast::error_code ec,
                    tcp::resolver::results_type results) {
        if (ec) {
            std::cerr << "Resolve: " << ec.message() << "\n";
            return;
        }

        beast::get_lowest_layer(ws_).async_connect(results,
            beast::bind_front_handler(&CompleteWebSocketClient::on_connect,
                                     shared_from_this()));
    }

    void on_connect(beast::error_code ec,
                    tcp::resolver::results_type::endpoint_type ep) {
        if (ec) {
            std::cerr << "Connect: " << ec.message() << "\n";
            return;
        }

        ws_.async_handshake(host_, path_,
            beast::bind_front_handler(&CompleteWebSocketClient::on_handshake,
                                     shared_from_this()));
    }

    void on_handshake(beast::error_code ec) {
        if (ec) {
            std::cerr << "Handshake: " << ec.message() << "\n";
            return;
        }

        std::cout << "WebSocket connected\n";
        do_read();
        start_ping();
    }

    void do_read() {
        ws_.async_read(buffer_,
            beast::bind_front_handler(&CompleteWebSocketClient::on_read,
                                     shared_from_this()));
    }

    void on_read(beast::error_code ec, std::size_t bytes) {
        if (ec) {
            if (ec != websocket::error::closed) {
                std::cerr << "Read: " << ec.message() << "\n";
            }
            return;
        }

        std::cout << "Received: "
                  << beast::buffers_to_string(buffer_.data()) << "\n";
        buffer_.consume(buffer_.size());
        do_read();
    }

    void start_ping() {
        ping_timer_.expires_after(std::chrono::seconds(30));
        ping_timer_.async_wait(
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) return;
                self->ws_.async_ping({},
                    [self](beast::error_code ec) {
                        if (!ec) self->start_ping();
                    });
            });
    }
};

Async echo server

class CompleteWebSocketSession
    : public std::enable_shared_from_this<CompleteWebSocketSession> {
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;

public:
    explicit CompleteWebSocketSession(tcp::socket socket)
        : ws_(std::move(socket)) {}

    void run() {
        ws_.set_option(websocket::stream_base::timeout::suggested(
            beast::role_type::server));
        ws_.read_message_max(64 * 1024);  // 64 KiB cap

        ws_.async_accept(
            beast::bind_front_handler(&CompleteWebSocketSession::on_accept,
                                     shared_from_this()));
    }

private:
    void on_accept(beast::error_code ec) {
        if (ec) {
            std::cerr << "Accept: " << ec.message() << "\n";
            return;
        }

        do_read();
    }

    void do_read() {
        ws_.async_read(buffer_,
            beast::bind_front_handler(&CompleteWebSocketSession::on_read,
                                     shared_from_this()));
    }

    void on_read(beast::error_code ec, std::size_t) {
        if (ec) {
            if (ec == websocket::error::closed) {
                std::cout << "Connection closed normally\n";
            } else {
                std::cerr << "Read: " << ec.message() << "\n";
            }
            return;
        }

        ws_.text(ws_.got_text());
        ws_.async_write(buffer_.data(),
            beast::bind_front_handler(&CompleteWebSocketSession::on_write,
                                     shared_from_this()));
    }

    void on_write(beast::error_code ec, std::size_t) {
        if (ec) {
            std::cerr << "Write: " << ec.message() << "\n";
            return;
        }

        buffer_.consume(buffer_.size());
        do_read();
    }
};

5. Common errors

Error 1: Handshake 400 Bad Request

Symptom: beast::http::error::bad_request Cause:

  • Missing or malformed Sec-WebSocket-Key
  • Wrong Upgrade token / casing
  • Missing Connection: Upgrade Fix:
// Beast generates correct headers
// manual implementations must follow RFC 6455
ws_.async_handshake(host, path,
     {
        if (ec == beast::http::error::bad_request) {
            std::cerr << "Check Upgrade, Connection, Sec-WebSocket-Key\n";
        }
    });

Error 2: bad_version (426 Upgrade Required)

Symptom: server returns 426 Cause: Sec-WebSocket-Version ≠ 13 Fix: Beast defaults to 13; manual stacks must send 13.

Error 3: connection_reset / connection_aborted

Symptom: read/write fails mid-flight Cause:

  • NAT/firewall idle timeout
  • server restart
  • flaky network Fix: heartbeats + reconnect policy
ws_.async_read(buffer_,
    [self = shared_from_this()](beast::error_code ec, std::size_t) {
        if (ec) {
            if (ec == net::error::connection_reset ||
                ec == net::error::connection_aborted) {
                self->schedule_reconnect();
            }
            return;
        }
        // ...
    });

Error 4: frame too big / payload too large

Symptom: websocket::error::message_too_big Cause: payload larger than read_message_max Fix:

// server: cap incoming messages
ws_.read_message_max(1024 * 1024);  // 1MB
// set the same limit on clients
ws_.read_message_max(1024 * 1024);

Error 5: Safari/Chrome WSS flakiness (multithreaded)

Symptom: random drops on Safari/macOS and some Chrome builds Cause: concurrent access to the same stream Fix: serialize with a strand

// stream bound to a strand
auto strand = net::make_strand(ioc);
websocket::stream<beast::tcp_stream> ws_(strand);
// every async op runs on that strand
ws_.async_read(buffer_, net::bind_executor(strand,  { ....}));

Error 6: Mask required (client → server)

Symptom: server rejects client frames Cause: RFC 6455 requires masking for client→server frames Fix: Beast masks automatically; manual stacks must set MASK.

Error 7: Invalid UTF-8 (text frames)

Symptom: websocket::error::bad_payload Cause: invalid UTF-8 in a text frame Fix:

// send as binary or validate UTF-8 first
ws_.binary(true);
ws_.async_write(net::buffer(data), ...);

Error 8: Double read (overlapping async_read)

Symptom: UB / crashes Cause: second async_read before the first completes Fix: chain reads only inside the completion handler

void on_read(beast::error_code ec, std::size_t) {
    if (ec) return;
    // handle ...
    do_read();  // schedule next read here only
}

6. Best practices

1. Cap message size

// rough guidance
// chat JSON: 64 KiB
// JSON API: 1MB
// binary streaming: up to 10 MiB (watch memory)
ws_.read_message_max(64 * 1024);

2. Reconnect with exponential backoff

void schedule_reconnect() {
    static int attempt = 0;
    auto delay = std::min(
        std::chrono::seconds(1) << attempt,
        std::chrono::seconds(60));
    ++attempt;

    reconnect_timer_.expires_after(delay);
    reconnect_timer_.async_wait(
        [this](beast::error_code ec) {
            if (!ec) {
                connect(host_, port_, path_);
                attempt = 0;  // reset after success
            }
        });
}

3. Graceful Close

void close() {
    ws_.async_close(websocket::close_code::normal,
        [self = shared_from_this()](beast::error_code ec) {
            if (ec) {
                beast::get_lowest_layer(self->ws_).close();
            }
        });
}

4. Broadcast backpressure

// ❌ bad: thousands of concurrent writes
for (auto& session : sessions_) {
    session->ws_.async_write(...);  // floods executor
}
// ✅ good: per-session queues
void broadcast(const std::string& msg) {
    for (auto& session : sessions_) {
        session->enqueue(msg);
    }
}
void enqueue(const std::string& msg) {
    bool was_empty = write_queue_.empty();
    write_queue_.push(msg);
    if (was_empty) do_write();
}
void do_write() {
    if (write_queue_.empty()) return;
    ws_.async_write(net::buffer(write_queue_.front()),
        [this](beast::error_code ec, std::size_t) {
            if (!ec) {
                write_queue_.pop();
                do_write();
            }
        });
}

5. Configure timeouts

websocket::stream_base::timeout opt{
    std::chrono::seconds(30),  // handshake timeout
    std::chrono::seconds(30),  // idle timeout
    false                     // keepalive pings
};
ws_.set_option(opt);

6. Logging

ws_.async_handshake(host, path,
    [host, path](beast::error_code ec) {
        if (ec) {
            spdlog::error("WebSocket handshake failed: {} {} {}",
                host, path, ec.message());
        }
    });

7. Production patterns

Pattern 1: connection limits

class WebSocketServer {
    std::atomic<int> connection_count_{0};
    static constexpr int max_connections_ = 10000;

    void do_accept() {
        acceptor_.async_accept(
            [this](beast::error_code ec, tcp::socket socket) {
                if (ec) return;

                if (connection_count_.load() >= max_connections_) {
                    socket.close();
                    spdlog::warn("Connection limit reached");
                } else {
                    connection_count_++;
                    std::make_shared<Session>(std::move(socket),
                        [this]() { connection_count_--; })->run();
                }
                do_accept();
            });
    }
};

Pattern 2: Graceful shutdown

void shutdown() {
    acceptor_.close();

    for (auto& session : sessions_) {
        session->ws_.async_close(websocket::close_code::going_away,
             {});
    }

    work_guard_.reset();
    ioc_.stop();
}

Pattern 3: Metrics

struct WebSocketMetrics {
    std::atomic<uint64_t> connections_total{0};
    std::atomic<uint64_t> connections_active{0};
    std::atomic<uint64_t> messages_received{0};
    std::atomic<uint64_t> messages_sent{0};
    std::atomic<uint64_t> errors_handshake{0};
    std::atomic<uint64_t> errors_read{0};
};
// export to Prometheus/Grafana/etc.
void on_handshake(beast::error_code ec) {
    if (ec) {
        metrics_.errors_handshake++;
        return;
    }
    metrics_.connections_active++;
}

Pattern 4: Subprotocol negotiation

// client
ws_.set_option(websocket::stream_base::decorator(
     {
        req.set(beast::http::field::sec_websocket_protocol,
               "chat, json");
    }));
// server: pick one during accept
ws_.set_option(websocket::stream_base::decorator(
     {
        res.set(beast::http::field::sec_websocket_protocol, "chat");
    }));

Pattern 5: WSS (TLS)

using ssl_stream = boost::asio::ssl::stream<beast::tcp_stream>;
websocket::stream<ssl_stream> wss_(ssl_ctx, net::make_strand(ioc));
// TLS first, then WebSocket upgrade
ssl_stream_.async_handshake(ssl::stream_base::client,
    [this](beast::error_code ec) {
        if (!ec) {
            wss_.async_handshake(host_, path_, ...);
        }
    });

8. Checklist

Handshake

  • Random 16-byte key, Base64
  • Sec-WebSocket-Accept SHA1+magic+Base64
  • Upgrade: websocket, Connection: Upgrade
  • Sec-WebSocket-Version: 13

Frames

  • Client→server frames masked
  • Validate UTF-8 for text frames
  • Configure read_message_max
  • Close frames include code + optional reason

Ping/Pong

  • Ping every 20–30s
  • Reconnect if Pong missing ~10s
  • Server answers Ping with Pong

Errors

  • connection_reset → reconnect
  • message_too_big → enforce caps
  • Log handshake failures; retry with backoff

Production

  • Use strands under concurrency
  • Exponential backoff reconnects
  • Enforce max concurrent sockets
  • Graceful shutdown
  • Metrics and structured logging

References

Summary

TopicDetail
HandshakeHTTP Upgrade + Sec-WebSocket-Key / Accept
FramesFIN, opcode, mask bit, payload
MaskingRequired client→server
Ping/Pong~30s heartbeat; reconnect if Pong missing ~10s
Errors400/426, connection_reset, message_too_big
Productionstrands, backpressure, backoff, metrics

FAQ

Handshake returns 400

Verify Sec-WebSocket-Key, Upgrade, and Connection. Beast sets these correctly when you use async_handshake / async_accept.

Safari drops WSS

Construct the stream on a strand (net::make_strand) and bind every async op to it.

Broadcast slows the server

Use per-session write queues and sequential writes (backpressure) instead of fanning out thousands of concurrent async_write calls.

What should I read first?

C++ WebSocket fundamentals #30-1, then this article.

Next: Protocol & serialization #30-3 (Korean)
Previous: WebSocket fundamentals #30-1

Keywords

C++, WebSocket, Beast, handshake, frames, Ping, Pong, production, errors.
