C++ WebSocket Complete Guide | Beast Handshake, Frames, Ping/Pong [#30-1]

이 글의 핵심

Hands-on WebSocket in C++ with Boost.Beast: RFC 6455 handshake, frame layout, masking, Ping/Pong heartbeats, async client/server, errors, and production patterns (Redis, sticky LB, metrics).

Introduction: “We need bidirectional real-time messaging”

Why HTTP polling breaks down

// ❌ Problem: polling wastes work
while (true) {
    auto response = httpGet("/api/messages");
    if (response.has_new_messages()) {
        process(response.messages);
    }
    std::this_thread::sleep_for(std::chrono::seconds(1));
}
// Issues:
// - Mostly empty responses
// - Up to one period of latency
// - Load scales with clients × poll rate

What goes wrong in production:

  • Latency bounded by the poll interval
  • Wasted requests when nothing changed
  • Load ≈ concurrent users × poll frequency
  • Cost from traffic and CPU spent on empty replies

More scenarios

Scenario 2: polling melts the server

Fifty thousand users polling once per second is fifty thousand HTTP transactions per second. WebSocket keeps one socket per subscriber, which usually shrinks overhead dramatically. Scenario 3: market data latency

A five-second poll means quotes can be five seconds stale—unacceptable for low-latency trading. Push over WebSocket delivers updates as they arrive. Scenario 4: lost messages after reconnect

Mobile backgrounds drop TCP sessions. Without sequence numbers or offsets, you cannot resume mid-stream after reconnect. Scenario 5: corporate proxies block upgrades

Some networks block Upgrade: websocket. Fallback strategies include long polling over HTTPS or WSS on port 443. How WebSocket helps:

// ✅ WebSocket: server pushes when data exists
ws.async_read(buffer,  {
    if (!ec) {
        process(buffer);
        ws.async_read(buffer, ...);
    }
});
// Benefits:
// - Event-driven delivery
// - One connection, bidirectional
// - No periodic polling loop

Goals:

  • Understand the WebSocket protocol (handshake, frames)
  • Use websocket::stream from Boost.Beast
  • Implement Ping/Pong heartbeats
  • Handle errors and reconnect
  • Compare WebSocket vs HTTP polling
  • Sketch production patterns (chat, dashboards) Prerequisites: Boost.Beast 1.70+ After reading you should be able to reason about frames in Wireshark, ship a Beast client/server, and tune timeouts for real networks.

Mental model

Think of sockets as addresses and async I/O as delivery routes: Asio schedules handlers (like workers) across threads; a strand keeps one connection’s work serialized.

Practical focus: examples come from large C++ services—edge cases that textbooks skip (Safari + TLS, masking, proxy timeouts).

Contents

  1. Protocol layout
  2. Handshake
  3. Frames
  4. Beast WebSocket client
  5. Beast WebSocket server
  6. Ping/Pong heartbeat
  7. Common errors
  8. Best practices
  9. Performance
  10. Production examples

1. WebSocket protocol layout

Connection lifecycle

sequenceDiagram
    participant C as Client
    participant S as Server

    C->>S: HTTP GET /ws\nUpgrade: websocket\nSec-WebSocket-Key: xxx
    S->>C: HTTP 101 Switching Protocols\nSec-WebSocket-Accept: yyy

    Note over C,S: WebSocket established

    C->>S: WebSocket Frame (Text)
    S->>C: WebSocket Frame (Text)
    C->>S: Ping
    S->>C: Pong
    C->>S: Close
    S->>C: Close

Connection state machine

stateDiagram-v2
    [*] --> Connecting: TCP connect
    Connecting --> Open: 101 Switching Protocols
    Connecting --> [*]: 400/403 etc.
    Open --> Closing: Close frame received
    Open --> [*]: Abrupt drop
    Closing --> [*]: Close complete

HTTP vs WebSocket

AspectHTTPWebSocket
ConnectionOften per requestLong-lived
DirectionRequest/responseBidirectional
OverheadLarge HTTP headersSmall frame header (2–14 B)
TimelinessNeeds pollingPush
LoadHigh with pollingEvent-driven

2. Handshake

Client request

GET /chat HTTP/1.1
Host: example.com
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Key: dGhlIHNhbXBsZSBub25jZQ==
Sec-WebSocket-Version: 13

Important headers:

  • Upgrade: websocket — request protocol switch
  • Connection: Upgrade — HTTP upgrade hop
  • Sec-WebSocket-Key — random 16 bytes, Base64
  • Sec-WebSocket-Version: 13 — only standardized version

Server response

HTTP/1.1 101 Switching Protocols
Upgrade: websocket
Connection: Upgrade
Sec-WebSocket-Accept: s3pPLMBiTxaQ9kYGzzhZRbK+xOo=

Raw bytes (first lines of the client request as sent on the wire):

47 45 54 20 2f 63 68 61 74 20 48 54 54 50 2f 31  GET /chat HTTP/1
2e 31 0d 0a 48 6f 73 74 3a 20 65 78 61 6d 70 6c  .1..Host: exampl
65 2e 63 6f 6d 0d 0a 55 70 67 72 61 64 65 3a 20  e.com..Upgrade:
77 65 62 73 6f 63 6b 65 74 0d 0a 43 6f 6e 6e 65  websocket..Conne
63 74 69 6f 6e 3a 20 55 70 67 72 61 64 65 0d 0a  ction: Upgrade..

Computing Sec-WebSocket-Accept:

#include <openssl/sha.h>
#include <boost/beast/core/detail/base64.hpp>
std::string computeAccept(const std::string& key) {
    // RFC 6455: key + "258EAFA5-E914-47DA-95CA-C5AB0DC85B11"
    std::string magic = "258EAFA5-E914-47DA-95CA-C5AB0DC85B11";
    std::string input = key + magic;

    // SHA-1
    unsigned char hash[SHA_DIGEST_LENGTH];
    SHA1(reinterpret_cast<const unsigned char*>(input.c_str()),
         input.size(), hash);

    // Base64
    std::string result;
    result.resize(boost::beast::detail::base64::encoded_size(SHA_DIGEST_LENGTH));
    result.resize(boost::beast::detail::base64::encode(
        &result[0], hash, SHA_DIGEST_LENGTH));

    return result;
}

Handshake flow

flowchart TB
    Start[TCP connect] --> ClientReq[Client: HTTP Upgrade]
    ClientReq --> ServerCheck{Server: valid?}
    ServerCheck -->|Yes| ServerResp[Server: 101 Switching Protocols]
    ServerCheck -->|No| ServerErr[Server: 400 Bad Request]
    ServerResp --> WSOpen[WebSocket open]
    ServerErr --> Close[Connection closed]
    WSOpen --> DataExchange[Data frames]

    style WSOpen fill:#4caf50
    style ServerErr fill:#f44336

3. Frames

Frame layout

graph LR
    A[FINbr/1bit] --> B[RSVbr/3bits]
    B --> C[Opcodebr/4bits]
    C --> D[Maskbr/1bit]
    D --> E["Payload Lenbr/7bits"]
    E --> F["Extendedbr/Payload Len"]
    F --> G["Masking Keybr/4bytes"]
    G --> H[Payload Data]

    style A fill:#ff9800
    style C fill:#4caf50
    style D fill:#2196f3

Opcodes

OpcodeValueRole
Continuation0x0Continues previous fragment
Text0x1UTF-8 text
Binary0x2Binary payload
Close0x8Close connection
Ping0x9Heartbeat probe
Pong0xAHeartbeat reply

Close frames

// Beast: graceful close
ws_.close(websocket::close_code::normal);
// Optional close reason string
ws_.close(websocket::close_code::normal, "server shutting down");
// In read handler when closed
if (ec == websocket::error::closed) {
    auto reason = ws_.reason();
    // reason.code (1000 normal, 1001 going away, ...)
    // reason.reason (UTF-8 string)
}

Masking

Rule: client → server frames must be masked.

// XOR mask
void mask_payload(uint8_t* data, size_t len, const uint8_t mask_key[4]) {
    for (size_t i = 0; i < len; ++i) {
        data[i] ^= mask_key[i % 4];
    }
}

Why: mitigates cache poisoning on misbehaving intermediaries.

Worked example: text “Hi”

Raw bytes when the client sends two bytes of UTF-8 text:

Byte 0: 0x81  (FIN=1, RSV=0, opcode Text)
Byte 1: 0x82  (MASK=1, payload len=2)
Bytes 2–5: 4-byte masking key (example 0x37 0xfa 0x21 0x3d)
Bytes 6–7: "Hi" XOR mask → 0x7b 0x9b (masked payload)

Sending with Beast (masking applied automatically in client role):

// Beast masks client→server frames for you
ws_.text(true);
ws_.async_write(net::buffer("Hi"),
     {
        if (!ec) {
            // 2 B payload + 2–14 B header on the wire
        }
    });

4. Beast WebSocket client

Minimal synchronous client

#include <boost/beast.hpp>
#include <boost/asio.hpp>
#include <iostream>
namespace beast = boost::beast;
namespace websocket = beast::websocket;
namespace net = boost::asio;
using tcp = net::ip::tcp;
class WebSocketClient {
    net::io_context& ioc_;
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;

public:
    explicit WebSocketClient(net::io_context& ioc)
        : ioc_(ioc), ws_(net::make_strand(ioc)) {}

    void connect(const std::string& host, const std::string& port) {
        // Resolve host
        tcp::resolver resolver(ioc_);
        auto results = resolver.resolve(host, port);

        // TCP connect
        net::connect(ws_.next_layer(), results);

        // WebSocket handshake
        ws_.handshake(host, "/");

        std::cout << "WebSocket connected to " << host << "\n";
    }

    void send(const std::string& message) {
        ws_.write(net::buffer(message));
    }

    std::string receive() {
        buffer_.clear();
        ws_.read(buffer_);

        return beast::buffers_to_string(buffer_.data());
    }

    void close() {
        ws_.close(websocket::close_code::normal);
    }
};
// Example
int main() {
    net::io_context ioc;

    WebSocketClient client(ioc);
    client.connect("echo.websocket.org", "80");

    client.send("Hello, WebSocket!");
    std::string response = client.receive();
    std::cout << "Received: " << response << "\n";

    client.close();
}

Async client

class AsyncWebSocketClient : public std::enable_shared_from_this<AsyncWebSocketClient> {
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;

public:
    explicit AsyncWebSocketClient(net::io_context& ioc)
        : ws_(net::make_strand(ioc)) {}

    void connect(const std::string& host, const std::string& port) {
        tcp::resolver resolver(ws_.get_executor());

        resolver.async_resolve(host, port,
            [self = shared_from_this(), host](
                beast::error_code ec,
                tcp::resolver::results_type results) {

                if (ec) {
                    std::cerr << "Resolve error: " << ec.message() << "\n";
                    return;
                }

                // TCP connect
                beast::get_lowest_layer(self->ws_).async_connect(results,
                    [self, host](beast::error_code ec, tcp::endpoint) {
                        if (ec) {
                            std::cerr << "Connect error: " << ec.message() << "\n";
                            return;
                        }

                        // WebSocket handshake
                        self->ws_.async_handshake(host, "/",
                            [self](beast::error_code ec) {
                                if (ec) {
                                    std::cerr << "Handshake error: " << ec.message() << "\n";
                                    return;
                                }

                                std::cout << "WebSocket connected\n";
                                self->do_read();
                            });
                    });
            });
    }

    void send(const std::string& message) {
        ws_.async_write(net::buffer(message),
             {
                if (ec) {
                    std::cerr << "Write error: " << ec.message() << "\n";
                }
            });
    }

private:
    void do_read() {
        auto self = shared_from_this();

        ws_.async_read(buffer_,
            [self](beast::error_code ec, std::size_t bytes) {
                if (ec) {
                    if (ec != websocket::error::closed) {
                        std::cerr << "Read error: " << ec.message() << "\n";
                    }
                    return;
                }

                std::cout << "Received: "
                          << beast::buffers_to_string(self->buffer_.data()) << "\n";

                self->buffer_.clear();
                self->do_read();  // wait for next message
            });
    }
};

5. Beast WebSocket server

Echo server sketch

class WebSocketSession : public std::enable_shared_from_this<WebSocketSession> {
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;

public:
    explicit WebSocketSession(tcp::socket socket)
        : ws_(std::move(socket)) {}

    void run() {
        // Suggested timeouts
        ws_.set_option(websocket::stream_base::timeout::suggested(
            beast::role_type::server));

        ws_.set_option(websocket::stream_base::decorator(
             {
                res.set(beast::http::field::server, "Beast WebSocket Server");
            }));

        // Accept HTTP upgrade
        ws_.async_accept(
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) {
                    std::cerr << "Accept error: " << ec.message() << "\n";
                    return;
                }

                self->do_read();
            });
    }

private:
    void do_read() {
        auto self = shared_from_this();

        ws_.async_read(buffer_,
            [self](beast::error_code ec, std::size_t) {
                if (ec) {
                    if (ec == websocket::error::closed) {
                        std::cout << "Connection closed\n";
                    } else {
                        std::cerr << "Read error: " << ec.message() << "\n";
                    }
                    return;
                }

                // Echo: preserve text/binary flag
                self->ws_.text(self->ws_.got_text());
                self->ws_.async_write(self->buffer_.data(),
                    [self](beast::error_code ec, std::size_t) {
                        if (ec) {
                            std::cerr << "Write error: " << ec.message() << "\n";
                            return;
                        }

                        self->buffer_.clear();
                        self->do_read();
                    });
            });
    }
};
class WebSocketServer {
    net::io_context& ioc_;
    tcp::acceptor acceptor_;

public:
    WebSocketServer(net::io_context& ioc, uint16_t port)
        : ioc_(ioc),
          acceptor_(ioc, tcp::endpoint(tcp::v4(), port)) {}

    void run() {
        do_accept();
    }

private:
    void do_accept() {
        acceptor_.async_accept(
            net::make_strand(ioc_),
            [this](beast::error_code ec, tcp::socket socket) {
                if (!ec) {
                    std::make_shared<WebSocketSession>(std::move(socket))->run();
                }

                do_accept();
            });
    }
};
int main() {
    net::io_context ioc{1};

    WebSocketServer server(ioc, 8080);
    server.run();

    std::cout << "WebSocket server listening on port 8080\n";

    ioc.run();
}

6. Ping/Pong Heartbeat

Ping/Pong sequence

sequenceDiagram
    participant C as Client
    participant S as Server

    Note over C: Ping every 30s
    C->>S: Ping
    S->>C: Pong

    Note over C: keepalive OK

    C->>S: Ping
    Note over S: no Pong (dead peer)

    Note over C: timeout → reconnect

Ping timer

class WebSocketClientWithPing : public std::enable_shared_from_this<WebSocketClientWithPing> {
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;
    net::steady_timer ping_timer_;

public:
    explicit WebSocketClientWithPing(net::io_context& ioc)
        : ws_(net::make_strand(ioc)),
          ping_timer_(ws_.get_executor()) {}

    void start_ping() {
        ping_timer_.expires_after(std::chrono::seconds(30));

        ping_timer_.async_wait(
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) return;

                // Send ping
                self->ws_.async_ping({},
                    [self](beast::error_code ec) {
                        if (ec) {
                            std::cerr << "Ping error: " << ec.message() << "\n";
                            return;
                        }

                        self->start_ping();  // schedule next ping
                    });
            });
    }
};

Automatic Pong

Beast replies to Ping with Pong by default. For logging or custom behavior:

ws_.control_callback(
     {
        if (kind == websocket::frame_type::ping) {
            std::cout << "Received Ping\n";
            // Beast still sends Pong unless you take over
        } else if (kind == websocket::frame_type::pong) {
            std::cout << "Received Pong\n";
        }
    });

Heartbeat with Pong timeout

Example pattern: reconnect if Pong is missing:

class WebSocketWithHeartbeat : public std::enable_shared_from_this<WebSocketWithHeartbeat> {
    websocket::stream<beast::tcp_stream> ws_;
    beast::flat_buffer buffer_;
    net::steady_timer ping_timer_;
    net::steady_timer pong_timer_;
    bool pong_received_ = true;

public:
    void start_heartbeat() {
        pong_received_ = true;
        schedule_ping();
    }

private:
    void schedule_ping() {
        ping_timer_.expires_after(std::chrono::seconds(30));
        ping_timer_.async_wait(
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) return;

                if (!self->pong_received_) {
                    std::cerr << "Pong timeout - reconnecting\n";
                    self->reconnect();
                    return;
                }

                self->pong_received_ = false;
                self->ws_.async_ping({},
                    [self](beast::error_code ec) {
                        if (ec) return;
                        self->schedule_pong_timeout();
                        self->schedule_ping();
                    });
            });
    }

    void schedule_pong_timeout() {
        pong_timer_.expires_after(std::chrono::seconds(10));
        pong_timer_.async_wait(
            [self = shared_from_this()](beast::error_code ec) {
                if (ec) return;
                if (!self->pong_received_) {
                    self->ws_.close(websocket::close_code::normal);
                }
            });
    }

    void setup_control_callback() {
        ws_.control_callback(
            [self = shared_from_this()](websocket::frame_type kind, beast::string_view) {
                if (kind == websocket::frame_type::pong) {
                    self->pong_received_ = true;
                }
            });
    }

    void reconnect() { /* ... */ }
};

7. Common failures

Handshake errors

Typical causes: bad Sec-WebSocket-Key, wrong version.

// Error handling
ws_.async_handshake(host, "/",
     {
        if (ec) {
            if (ec == beast::http::error::bad_version) {
                std::cerr << "WebSocket version mismatch\n";
            } else if (ec == beast::http::error::bad_method) {
                std::cerr << "Invalid HTTP method\n";
            } else {
                std::cerr << "Handshake error: " << ec.message() << "\n";
            }
        }
    });

Frame parsing

Typical causes: missing mask, illegal opcode.

SymptomCauseMitigation
Mask requiredclient sent unmasked payloaduse Beast client or mask manually
Invalid opcodebug or attackvalidate before parsing
Payload too largeexceeds capset read_message_max

Safari + WSS drops (use a strand)

Symptom: macOS Safari closes WSS when async work races across threads.
Fix: run every async op on one strand.

auto strand = net::make_strand(ioc);
// bind async ops to strand
ws_.async_handshake(host, "/",
    net::bind_executor(strand,  {
        // ...
    }));
ws_.async_read(buffer_,
    net::bind_executor(strand,  {
        // ...
    }));

Connection timeout

Typical causes: firewall, wrong host/port, flaky Wi‑Fi.

// ❌ async_connect without deadline → can hang forever
beast::get_lowest_layer(ws_).async_connect(results, ...);
// ✅ set deadline / timeout on tcp_stream
beast::get_lowest_layer(ws_).expires_after(std::chrono::seconds(10));
beast::get_lowest_layer(ws_).async_connect(results,
     {
        if (ec == net::error::operation_aborted) {
            std::cerr << "Connection timeout\n";
        }
    });

400 / 403 on upgrade

Typical causes: Origin mismatch, subprotocol mismatch, auth failure.

// Example: reject unknown origins in decorator
ws_.set_option(websocket::stream_base::decorator(
     {
        auto origin = res[beast::http::field::origin];
        if (origin != "https://myapp.com") {
            res.result(beast::http::status::forbidden);
        }
    }));

Payload too large (DoS)

Cause: malicious multi‑gigabyte frames.

// Beast default max is large; cap explicitly
ws_.read_message_max(1024 * 1024);  // 1 MiB
// overflow → websocket::error::message_too_big
ws_.async_read(buffer_,  {
    if (ec == websocket::error::message_too_big) {
        ws_.close(websocket::close_code::too_big);
    }
});

Concurrent read/write (data races)

Cause: overlapping async_read/async_write on the same stream without serialization.

// ❌ overlapping writes from multiple callbacks
void do_read() {
    ws_.async_read(buffer_, [this](...) {
        ws_.async_write(...);  // another thread may also call do_read
        do_read();
    });
}
// ✅ construct stream on a strand
ws_ = websocket::stream<beast::tcp_stream>(net::make_strand(ioc));

shared_ptr cycles with timers

Cause: timers capture shared_from_this() and never cancel.

// ❌ timer keeps session alive forever
ping_timer_.async_wait([self = shared_from_this()](...) {
    self->ws_.async_ping(...);
});
// ✅ use weak_ptr for heartbeat callbacks
auto weak = std::weak_ptr<Session>(shared_from_this());
ping_timer_.async_wait([weak](beast::error_code ec) {
    auto self = weak.lock();
    if (!self || ec) return;
    // ...
});

8. Best practices

Serialize with a strand

Run all async operations for one connection on a single strand to avoid overlapping read/write crashes.

websocket::stream<beast::tcp_stream> ws_{net::make_strand(ioc)};

Timeouts

ws_.set_option(websocket::stream_base::timeout::suggested(beast::role_type::server));
// Suggested defaults differ for server vs client roles (idle + handshake)

Cap message size

ws_.read_message_max(1024 * 1024);  // 1 MiB

Reconnect with exponential backoff

void reconnect_with_backoff() {
    auto delay = std::min(
        base_delay_ * (1 << retry_count_),
        std::chrono::seconds(60)
    );
    retry_timer_.expires_after(delay);
    retry_timer_.async_wait([this](beast::error_code ec) {
        if (!ec) {
            connect();
            retry_count_ = std::min(retry_count_ + 1, 10);
        }
    });
}

Structured logging

struct WsError {
    beast::error_code ec;
    std::string context;
    std::chrono::system_clock::time_point when;
};
// Ship JSON logs to your observability stack

Checklist

  • Serialize async ops with a strand
  • Set read_message_max (~1 MiB typical for JSON chat)
  • Apply timeout::suggested or explicit deadlines
  • Ping ~30s; reconnect if Pong missing
  • weak_ptr in heartbeat timers
  • Optional control_callback tracing

9. Performance snapshot

WebSocket vs HTTP polling

Example: 10k concurrent users, one event per user per minute.

ModeRequests/minBandwidth (illustrative)Latency
HTTP poll (1s)600,000largeup to 1s
Long poll~10,000mediumup to hold window
WebSocket~10,000smallpush
Takeaway: polling wastes bandwidth when updates are rare; WebSocket removes periodic HTTP overhead.

Order-of-magnitude resources

Concurrent socketsRAMCPU
1,000tens of MBlow %
10,000hundreds of MBmid teens %
100,000multi‑GBworkload dependent

10. Production sketches

Chat fan-out

class ChatServer {
    std::set<std::shared_ptr<WebSocketSession>> sessions_;
    std::mutex mutex_;

public:
    void join(std::shared_ptr<WebSocketSession> session) {
        std::lock_guard<std::mutex> lock(mutex_);
        sessions_.insert(session);
    }

    void leave(std::shared_ptr<WebSocketSession> session) {
        std::lock_guard<std::mutex> lock(mutex_);
        sessions_.erase(session);
    }

    void broadcast(const std::string& message) {
        std::lock_guard<std::mutex> lock(mutex_);

        for (auto& session : sessions_) {
            session->send(message);
        }
    }
};

Live dashboard

class DashboardServer {
    std::map<std::string, std::shared_ptr<WebSocketSession>> subscribers_;

public:
    void subscribe(const std::string& topic, std::shared_ptr<WebSocketSession> session) {
        subscribers_[topic] = session;
    }

    void publish(const std::string& topic, const nlohmann::json& data) {
        auto it = subscribers_.find(topic);
        if (it != subscribers_.end()) {
            it->second->send(data.dump());
        }
    }

    // push metrics every second (example)
    void pushMetrics() {
        nlohmann::json metrics = {
            {"cpu", getCpuUsage()},
            {"memory", getMemoryUsage()},
            {"requests", getRequestCount()}
        };

        publish("metrics", metrics);
    }
};

Load balancer + sticky sessions

Stateful features often need sticky sessions (same client → same backend) unless you externalize all fan-out (Redis, etc.).

# Nginx example
upstream websocket_backend {
    ip_hash;  # pin client IP to one upstream
    server 10.0.1.1:8080;
    server 10.0.1.2:8080;
}
location /ws {
    proxy_pass http://websocket_backend;
    proxy_http_version 1.1;
    proxy_set_header Upgrade $http_upgrade;
    proxy_set_header Connection "Upgrade";
    proxy_read_timeout 3600s;
    proxy_send_timeout 3600s;
}

Horizontal scale (Redis Pub/Sub)

Broadcast across nodes when connections are not all local:

// Node A publishes after handling a chat event
redis.publish("chat:room1", message);
// Nodes B/C subscribed to the channel forward to local room members
redis.subscribe("chat:room1", [this](const std::string& msg) {
    for (auto& session : room1_sessions_) {
        session->send(msg);
    }
});

Health checks

// For Kubernetes/ECS, expose a plain HTTP /health (200 OK) on a separate port
// WebSocket-specific probes often use synthetic Ping/Pong or TCP checks

Production rollout checklist

  • Prefer WSS on 443
  • Configure LB stickiness when sessions are local
  • Set proxy_read_timeout above heartbeat interval (often 3600s)
  • Use Redis or a message bus for cross-node fan-out
  • Metrics: active connections, msgs/sec, handshake failures
  • Client reconnect with exponential backoff

References

Keywords

C++ WebSocket, Boost.Beast, handshake, frames, Ping, Pong, real-time.

Summary

TopicDetail
Wire formatHTTP upgrade → framed messages
HandshakeSec-WebSocket-Key / Sec-WebSocket-Accept
FramesOpcodes for text, binary, ping, pong, close
MaskingRequired client→server
HeartbeatPing/Pong + app-level keepalives
OpsWSS, LB timeouts, Redis fan-out, metrics

FAQ

When do I need this in production?

Any bidirectional real-time workload: chat, market data, games, dashboards, notifications.

How much better than polling?

Polling issues scale with users × poll rate; WebSocket removes that multiplier for push-heavy workloads.

Safari drops my WSS connection

Serialize every async WebSocket operation on a strand (see above).

Continue the series: WebSocket deep dive #30-2, TLS #30-2.

Where to study deeper?

RFC 6455 and the official Beast docs.

Next: C++ guide #30-2 — SSL/TLS with OpenSSL and Asio
Previous: Multithreaded servers — io_context pools and strands

See also

  • C++ WebSocket deep dive | errors & production patterns
