Build a Minimal C++ HTTP Framework from Scratch with Asio [#48-2]

Introduction: “A tiny Express-style HTTP stack in C++“

Why build it yourself?

Production HTTP servers combine routing, middleware, and async I/O. Boost.Beast or Crow are the right defaults for shipping code. A from-scratch minimal stack still helps when:

1. Embedded / tight resources — whole Beast may be too large; a small parser + router fits in tens of KB.
2. Mixed protocols — HTTP + WebSocket + custom TCP on one port; owning the pipeline helps.
3. Learning / interviews — explaining routing tables and middleware chains is easier after you have built one.
4. Minimal dependencies — only Asio, no full framework.

This article covers:

• Parsing: request line, headers, body (line-by-line or small state machine)
• Routing: method + path → handler (unordered_map or trie)
• Middleware: wrap Next, logging, auth, shared headers
• Async: accept → read → parse → handler → async_write

Prerequisites: Asio intro, Redis clone sessions.

Environment: Boost.Asio or standalone Asio, C++14+, e.g. vcpkg install boost-asio.

---

Architecture

• io_context + tcp::acceptor accept connections; each session uses async_read_until / async_read until \r\n\r\n, then optional body via Content-Length.
• Parsed Request → Router → middleware chain → handler → serialize Response → async_write.

flowchart TB
    subgraph Client["Client"]
        C1[HTTP request]
    end
    subgraph Server["Server"]
        A[Acceptor] --> S[Session]
        S --> P[HTTP parser]
        P --> R[Router]
        R --> M[Middleware chain]
        M --> H[Handler]
        H --> W[async_write]
    end
    C1 --> A
    W --> C2[HTTP response]
    C2 --> Client

Parsing state (conceptual): request line → headers until blank line → optional body by Content-Length.

Routing: using Handler = std::function<Response(Request const&)>; keyed by (method, path).

Middleware: using Next = std::function<Response(Request const&)>; and Middleware = std::function<Response(Request const&, Next const&)>.

Async note: Handler + router can stay synchronous on a single thread; serialize Response to HTTP bytes and async_write. For multiple io_context::run threads, use a strand or make router read-only after init—see strand guide.

---

Common failures (summary)

Issue	Mitigation
Connection reset / EOF	Treat eof / connection_reset as normal close
Chunked / missing Content-Length	Minimal server may skip body; full servers need chunked support
\r left on lines	Strip trailing \r after getline
Use-after-free in handlers	shared_from_this in async lambdas
Huge bodies	Cap Content-Length (e.g. 413)
Keep-alive buffer reuse	buffer_.consume after each request

---

Performance (rule of thumb)

Rough localhost numbers: minimal parser + map routing ~15k req/s; Beast-based higher; nginx much higher. Profile your real workload—DB and I/O usually dominate.

---

Production patterns

• Cap concurrent connections; request timeouts; structured logging; graceful shutdown on SIGINT/SIGTERM; /health endpoint.

Library	Notes
Boost.Beast	Production HTTP/WebSocket on Asio
Crow	Header-only, Express-like
Drogon	Full async stack, C++17
Custom	Learning, embedded, tight control

---

Related posts

• REST API with Beast
• HTTP basics
• Redis clone

---

FAQ

Q. When do I use this in production?
A. Prefer Beast/Crow for real services. Use this article for design literacy and custom minimal stacks.

Q. Next article?
A. Memory pool (#48-3)

Q. More reading?
A. cppreference, Boost.Beast docs.

---

Summary

Piece	Idea
Flow	Acceptor → Session → Parser → Router → Middleware → Handler → write
Routing	(method, path) → handler
Middleware	Pre/post around next(req)
Safety	error_code, shared_from_this, body limits

Previous: Redis clone #48-1
Next: Memory pool #48-3
