Cache-Friendly C++: Data-Oriented Design Guide

Introduction: cache decides throughput

Modern CPUs are often memory bound. Data-oriented design (DoD) lays out data for sequential access and SIMD. Structure-of-arrays (SoA) often beats array-of-structures (AoS) when loops touch few fields of many objects. False sharing kills parallel scaling unless you pad or align per-thread counters to separate cache lines (~64 bytes).

This article covers: DoD, cache lines, alignas, false sharing, scenarios, AoS→SoA examples, pitfalls, benchmarks, engine/simulation patterns.

---

Table of contents

1. Why cache optimization matters
2. Data-oriented design
3. Cache lines & alignment
4. False sharing & padding
5. Complete examples
6. Common mistakes
7. Benchmarks
8. Production patterns
9. Summary

---

1. Why cache optimization matters

• 100k entities: updating position only still loads velocity/color/id in AoS → wasted bandwidth.
• More threads slower: false sharing on adjacent counters.
• SIMD won’t vectorize: AoS scatters x across strides.

---

2. Data-oriented design

flowchart TB
    subgraph AoS["AoS"]
        E1["Entity0: pos, vel, id"]
        E2["Entity1: ..."]
    end
    subgraph SoA["SoA"]
        X["x[]"]
        Y["y[]"]
        Z["z[]"]
    end
    AoS -->|"position-only loop"| Waste["Loads unused fields"]
    SoA -->|"position-only loop"| Hit["Sequential x,y,z"]

Rule of thumb: thousands+ entities, field-specific hot loops, SIMD → SoA. Small counts (<~100–1000) may favor simpler AoS.

---

3. Cache lines & alignment

Typical 64-byte lines. alignas(64) hot atomics/counters to separate lines. Use std::hardware_destructive_interference_size (C++17) when available.

---

4. False sharing

Independent variables on the same cache line invalidate each other across cores. Fix with line-sized padding or per-thread shards.

---

5. Complete examples

This series also walks through a full particle AoS vs SoA benchmark and padded atomic counters for parallel increments—adapt the code and comments to your codebase.

---

6. Common mistakes

• SoA index mismatch after partial deletes—use swap-with-last across all arrays.
• Over-padding everything—only hot written fields need isolation.
• SoA with random indices loses locality—sort/pack active entities.

---

7. Benchmarks

Use perf stat -e cache-misses,cache-references and Release (-O3 -march=native) builds.

---

8. Production patterns

ECS-style component arrays, batch processing, blocked matrix multiply, hybrid AoSoA blocks.

---

9. Summary

Topic	Takeaway
DoD	Prefer SoA when loops are field-specific
Cache line	64B, alignas for sharing avoidance
False sharing	pad or shard counters
Production	measure with perf, profile hot loops

---

Keywords

data-oriented design, cache optimization, AoS SoA, false sharing, cache line, SIMD
