C++ Sanitizers: ASan, TSan, UBSan, and MSan Explained

Introduction

Sanitizers are compiler-assisted tools that detect memory errors, data races, and undefined behavior at runtime. They are faster than Valgrind for many workflows and provide accurate stack traces so you can fix bugs quickly.

---

1. Sanitizer overview

Main sanitizers

# AddressSanitizer (ASan) — memory errors
g++ -fsanitize=address -g program.cpp -o program

# ThreadSanitizer (TSan) — data races
g++ -fsanitize=thread -g program.cpp -o program

# UndefinedBehaviorSanitizer (UBSan) — undefined behavior
g++ -fsanitize=undefined -g program.cpp -o program

# MemorySanitizer (MSan) — uninitialized memory
g++ -fsanitize=memory -g program.cpp -o program

# LeakSanitizer (LSan) — leaks (often bundled with ASan)
g++ -fsanitize=leak -g program.cpp -o program

Comparison

Sanitizer	Detects	Overhead	Pairing
ASan	Memory errors	~2×	ASan + UBSan
TSan	Data races	~5–15×	Alone
UBSan	Undefined behavior	~1.2×	ASan + UBSan
MSan	Uninitialized reads	~3×	Alone
LSan	Leaks	Low	Often with ASan

---

2. AddressSanitizer (ASan)

Buffer overflow

// bug1.cpp
#include <iostream>

int main() {
    int arr[10];

    // Bug: out of bounds
    for (int i = 0; i <= 10; ++i) {
        arr[i] = i;
    }

    return 0;
}

Build and run:

$ g++ -fsanitize=address -g bug1.cpp -o bug1
$ ./bug1

=================================================================
==12345==ERROR: AddressSanitizer: stack-buffer-overflow on address 0x7ffc...
WRITE of size 4 at 0x7ffc... thread T0
    #0 0x... in main bug1.cpp:8
    #1 0x... in __libc_start_main

Address 0x7ffc... is located in stack of thread T0 at offset 40 in frame
    #0 0x... in main bug1.cpp:4

Use-after-free

// bug2.cpp
#include <iostream>

int main() {
    int* ptr = new int(42);
    delete ptr;

    // Bug: use after free
    std::cout << *ptr << std::endl;

    return 0;
}

ASan output:

$ g++ -fsanitize=address -g bug2.cpp -o bug2
$ ./bug2

=================================================================
==12346==ERROR: AddressSanitizer: heap-use-after-free on address 0x602...
READ of size 4 at 0x602... thread T0
    #0 0x... in main bug2.cpp:7

0x602... is located 0 bytes inside of 4-byte region [0x602..., 0x602...)
freed by thread T0 here:
    #0 0x... in operator delete(void*)
    #1 0x... in main bug2.cpp:5

Memory leak

// bug3.cpp
#include <iostream>

int main() {
    // Bug: leak
    int* leak = new int(42);

    return 0;  // missing delete
}

ASan output:

$ g++ -fsanitize=address -g bug3.cpp -o bug3
$ ./bug3

=================================================================
==12347==ERROR: LeakSanitizer: detected memory leaks

Direct leak of 4 byte(s) in 1 object(s) allocated from:
    #0 0x... in operator new(unsigned long)
    #1 0x... in main bug3.cpp:5

---

3. ThreadSanitizer (TSan)

Data race

// race.cpp
#include <thread>
#include <iostream>

int counter = 0;

void increment() {
    for (int i = 0; i < 100000; ++i) {
        ++counter;  // data race!
    }
}

int main() {
    std::thread t1(increment);
    std::thread t2(increment);

    t1.join();
    t2.join();

    std::cout << "counter: " << counter << std::endl;

    return 0;
}

TSan output:

$ g++ -fsanitize=thread -g race.cpp -o race
$ ./race

==================
WARNING: ThreadSanitizer: data race (pid=12348)
  Write of size 4 at 0x... by thread T1:
    #0 increment() race.cpp:7

  Previous write of size 4 at 0x... by thread T2:
    #0 increment() race.cpp:7

Fix:

#include <atomic>
#include <thread>
#include <iostream>

std::atomic<int> counter{0};

void increment() {
    for (int i = 0; i < 100000; ++i) {
        ++counter;  // atomic
    }
}

int main() {
    std::thread t1(increment);
    std::thread t2(increment);

    t1.join();
    t2.join();

    std::cout << "counter: " << counter << std::endl;  // 200000

    return 0;
}

---

4. UndefinedBehaviorSanitizer (UBSan)

Undefined behavior

// ub.cpp
#include <iostream>

int main() {
    // Bug 1: division by zero
    int x = 0;
    int y = 5 / x;

    // Bug 2: signed overflow
    int max = 2147483647;
    int overflow = max + 1;

    // Bug 3: null pointer dereference
    int* ptr = nullptr;
    int value = *ptr;

    // Bug 4: out-of-bounds array index
    int arr[10];
    int index = 15;
    int val = arr[index];

    return 0;
}

UBSan output:

$ g++ -fsanitize=undefined -g ub.cpp -o ub
$ ./ub

ub.cpp:6:15: runtime error: division by zero
ub.cpp:10:23: runtime error: signed integer overflow: 2147483647 + 1 cannot be represented in type 'int'
ub.cpp:14:17: runtime error: load of null pointer of type 'int'
ub.cpp:19:17: runtime error: index 15 out of bounds for type 'int [10]'

---

5. CI/CD integration

CMake

# CMakeLists.txt
cmake_minimum_required(VERSION 3.15)
project(MyProject)

set(CMAKE_CXX_STANDARD 17)

option(ENABLE_ASAN "Enable AddressSanitizer" OFF)
option(ENABLE_TSAN "Enable ThreadSanitizer" OFF)
option(ENABLE_UBSAN "Enable UBSanitizer" OFF)

if(ENABLE_ASAN)
    add_compile_options(-fsanitize=address -fno-omit-frame-pointer)
    add_link_options(-fsanitize=address)
endif()

if(ENABLE_TSAN)
    add_compile_options(-fsanitize=thread)
    add_link_options(-fsanitize=thread)
endif()

if(ENABLE_UBSAN)
    add_compile_options(-fsanitize=undefined)
    add_link_options(-fsanitize=undefined)
endif()

add_executable(myapp main.cpp)

Build:

# ASan
cmake -DENABLE_ASAN=ON ..
make

# TSan
cmake -DENABLE_TSAN=ON ..
make

# UBSan
cmake -DENABLE_UBSAN=ON ..
make

GitHub Actions

# .github/workflows/sanitizers.yml
name: Sanitizers

on: [push, pull_request]

jobs:
  asan:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3

      - name: Build with ASan
        run: |
          g++ -fsanitize=address -g src/*.cpp -o test_asan

      - name: Run Tests
        run: ./test_asan

  tsan:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3

      - name: Build with TSan
        run: |
          g++ -fsanitize=thread -g src/*.cpp -o test_tsan

      - name: Run Tests
        run: ./test_tsan

  ubsan:
    runs-on: ubuntu-latest
    steps:
      - uses: actions/checkout@v3

      - name: Build with UBSan
        run: |
          g++ -fsanitize=undefined -g src/*.cpp -o test_ubsan

      - name: Run Tests
        run: ./test_ubsan

---

6. Common issues

Issue 1: Performance overhead

// Typical overhead:
// - ASan: ~2×
// - TSan: ~5–15×
// - UBSan: ~1.2×

// ✅ Dev/test only
// ✅ Strip from release builds

Issue 2: Compatibility

# ❌ ASan + TSan together (not supported this way)
g++ -fsanitize=address,thread program.cpp  # error

# ✅ Separate builds
g++ -fsanitize=address program.cpp  # ASan
g++ -fsanitize=thread program.cpp   # TSan

# ✅ ASan + UBSan is OK
g++ -fsanitize=address,undefined program.cpp

Issue 3: False positives / intentional patterns

// Suppress with attribute
__attribute__((no_sanitize("address")))
void intentionalOverflow() {
    // ...
}

// Or suppression file asan.supp

ASAN_OPTIONS=suppressions=asan.supp ./program

Issue 4: Debug symbols

# ❌ No -g (weaker stacks)
g++ -fsanitize=address program.cpp

# ✅ Add -g
g++ -fsanitize=address -g program.cpp

# ✅ Lower optimization for clearer traces
g++ -fsanitize=address -g -O1 program.cpp

---

7. Bug-hunting example

// buggy_program.cpp
#include <iostream>
#include <vector>
#include <thread>

class DataProcessor {
    std::vector<int> data;
    int counter = 0;

public:
    void leakyFunction() {
        int* leak = new int(42);
        // missing delete
    }

    void bufferOverflow() {
        int arr[10];
        for (int i = 0; i <= 10; ++i) {
            arr[i] = i;
        }
    }

    void useAfterFree() {
        int* ptr = new int(42);
        delete ptr;
        std::cout << *ptr << std::endl;
    }

    void dataRace() {
        auto increment = [this]() {
            for (int i = 0; i < 100000; ++i) {
                ++counter;  // no synchronization
            }
        };

        std::thread t1(increment);
        std::thread t2(increment);

        t1.join();
        t2.join();
    }

    void integerOverflow() {
        int max = 2147483647;
        int overflow = max + 1;
        std::cout << overflow << std::endl;
    }
};

int main() {
    DataProcessor processor;
    return 0;
}

Test script:

#!/bin/bash

echo "=== AddressSanitizer ==="
g++ -fsanitize=address -g buggy_program.cpp -o test_asan
./test_asan

echo "=== ThreadSanitizer ==="
g++ -fsanitize=thread -g buggy_program.cpp -o test_tsan
./test_tsan

echo "=== UBSanitizer ==="
g++ -fsanitize=undefined -g buggy_program.cpp -o test_ubsan
./test_ubsan

---

8. Sanitizer options

Environment variables

# ASan
export ASAN_OPTIONS=detect_leaks=1:halt_on_error=0

# TSan
export TSAN_OPTIONS=history_size=7:halt_on_error=0

# UBSan
export UBSAN_OPTIONS=print_stacktrace=1:halt_on_error=0

./program

Useful ASan options

ASAN_OPTIONS=detect_leaks=1
ASAN_OPTIONS=detect_stack_use_after_return=1
ASAN_OPTIONS=detect_container_overflow=1
ASAN_OPTIONS=log_path=asan.log
ASAN_OPTIONS=detect_leaks=1:log_path=asan.log:halt_on_error=0 ./program

---

Summary

Key takeaways

1. ASan: Memory errors (buffers, UAF, leaks)
2. TSan: Data races
3. UBSan: Undefined behavior (overflow, divide-by-zero)
4. MSan: Uninitialized memory
5. LSan: Leaks (often with ASan)
6. Cost: Dev/test only (~2–15×)

Choosing a sanitizer

Bug type	Sanitizer	When
Buffer overflow	ASan	Always in dev
Leaks	ASan / LSan	Always
Use-after-free	ASan	Always
Data race	TSan	Multithreaded code
Integer UB	UBSan	Arithmetic-heavy code
Uninit reads	MSan	Complex initialization

Practical tips

• Local dev: ASan + UBSan
• Threads: separate TSan build
• CI: automate sanitizer builds
• Release: no sanitizers

Next steps

• C++ Valgrind
• C++ GDB
• C++ memory leaks

---
