C++ Compilation Process Explained: Preprocess, Compile, Assemble, Link

· 11분 읽기 · 수정 Intermediate Tutorial
C++ Compilation Process Explained: Preprocess, Compile, Assemble, Link

이 글의 핵심

Walk through the four stages from source to executable: preprocessing, compilation, assembly, and linking. Name mangling occurs during compilation; symbol resolution happens at link time.

The compilation pipeline

From source to executable, C++ builds go through preprocessing → compilation → assembly → linking. Name mangling happens during compilation; symbol resolution happens at link time. Makefiles and include paths automate this workflow.

Source (.cpp) → preprocess → compile → assemble → link → executable

1. Preprocessing

// main.cpp
#include <iostream>
#define PI 3.14

int main() {
    std::cout << PI << std::endl;
}
# Inspect preprocessor output
g++ -E main.cpp -o main.i

2. Compilation

# C++ to assembly
g++ -S main.i -o main.s

3. Assembly

# Assembly to machine code
g++ -c main.s -o main.o

4. Linking

# Object file to executable
g++ main.o -o main

Practical examples

Example 1: Step-by-step build

# All-in-one
g++ main.cpp -o main

# Step by step
g++ -E main.cpp -o main.i    # preprocess
g++ -S main.i -o main.s      # compile
g++ -c main.s -o main.o      # assemble
g++ main.o -o main           # link

Example 2: Multiple sources

# Compile each file
g++ -c main.cpp -o main.o
g++ -c util.cpp -o util.o

# Link
g++ main.o util.o -o myapp

Example 3: Linking libraries

# Static library
g++ main.o -L./lib -lmylib -o myapp

# Shared library
g++ main.o -L./lib -lmylib -Wl,-rpath,./lib -o myapp

Example 4: Optimization flags

# Debug symbols
g++ -g main.cpp -o main

# Optimization
g++ -O2 main.cpp -o main

# Warnings
g++ -Wall -Wextra main.cpp -o main

Preprocessor directives

// Include
#include <iostream>   // system header
#include "myheader.h" // project header

// Macros
#define MAX 100
#define SQUARE(x) ((x) * (x))

// Conditional compilation
#ifdef DEBUG
    #define LOG(x) std::cout << x
#else
    #define LOG(x)
#endif

// Include guard
#ifndef MYHEADER_H
#define MYHEADER_H
// contents
#endif

Common issues

Issue 1: Missing header

// ❌ No header
int main() {
    std::cout << "Hello";  // error
}

// ✅ Include header
#include <iostream>
int main() {
    std::cout << "Hello";
}
# undefined reference
# → missing implementation or library not linked

g++ main.o -lmissing_lib -o myapp

Issue 3: Multiple definitions

// header.h
int globalVar = 10;  // ❌ ODR violation if included in multiple TUs

// ✅ Declaration only (header)
extern int globalVar;

// source.cpp
int globalVar = 10;  // single definition

Issue 4: Circular dependencies

// a.h
#include "b.h"

// b.h
#include "a.h"  // cycle

// ✅ Forward declaration
class B;  // forward declaration

Compiler options

# Language standard
g++ -std=c++17 main.cpp

# Warnings
g++ -Wall -Wextra -Werror main.cpp

# Optimization
g++ -O0  # none
g++ -O1  # basic
g++ -O2  # recommended for release
g++ -O3  # aggressive

# Debug
g++ -g main.cpp

# Preprocessor define
g++ -DDEBUG main.cpp

FAQ

Q1: What are the build stages?

A: Preprocessing → compilation → assembly → linking.

Q2: What is a .o file?

A: An object file. It contains machine code for one translation unit.

A:

  • Missing function definitions
  • Library not linked
  • Undefined symbols

Q4: Which optimization level?

A:

  • -O0: debugging
  • -O2: typical release builds
  • -O3: maximum optimization

Q5: How do I inspect preprocessing?

A: Use g++ -E.

Q6: Further reading?

A:

  • Linkers and Loaders
  • GCC documentation
  • C++ Primer

Related: Linking, Name mangling, Makefile, Include path.

Posts that connect well with this topic:

  • C++ Linking Guide
  • C++ Name Mangling
  • C++ Makefile Guide
  • C++ Include Path

Practical tips

Tips you can apply immediately.

Debugging

  • When something breaks, start with compiler warnings.
  • Reproduce issues with a minimal test case.

Performance

  • Do not optimize without profiling.
  • Define measurable metrics first.

Code review

  • Pre-check areas that reviews often flag.
  • Follow your team’s coding conventions.

Practical checklist

Things to verify when applying these ideas in real projects.

Before coding

  • Is this technique the best fit for the problem?
  • Can teammates understand and maintain this code?
  • Does it meet performance requirements?

While coding

  • Are all compiler warnings addressed?
  • Are edge cases considered?
  • Is error handling appropriate?

During review

  • Is intent clear?
  • Are tests sufficient?
  • Is documentation in place?

Use this checklist to reduce mistakes and improve quality.
