C++ Adapter Pattern: Complete Guide | Interface Wrapping & Legacy Integration

Structural patterns (Adapter, Decorator, Proxy, …) are surveyed in C++ structural patterns #19-2 and the overview #20-2. For a JS angle on wrapping APIs, see JavaScript patterns.

What is Adapter Pattern? why you need it

Problem Scenario: Incompatible Interfaces

Problem: The interface of an existing library is not compatible with my code.

// The interface my code expects
class MediaPlayer {
public:
    virtual void play(const std::string& filename) = 0;
};

// Existing library (not compatible)
class VLCPlayer {
public:
    void playVLC(const std::string& filename) { /* ... */ }
};

// How to use VLCPlayer as MediaPlayer?

Solution: Adapter Pattern converts interfaces. Adapter implements the Target interface and calls Adaptee internally.

// Adapter
class VLCAdapter : public MediaPlayer {
public:
    VLCAdapter(std::unique_ptr<VLCPlayer> player)
        : vlc(std::move(player)) {}

    void play(const std::string& filename) override {
vlc->playVLC(filename);  // interface conversion
    }

private:
    std::unique_ptr<VLCPlayer> vlc;
};

Key Concept: Adapter Pattern acts as a bridge to bridge incompatible interfaces. This is an essential pattern when integrating legacy systems or using third-party libraries.

---

index

1. Object Adapter
2. Class adapter
3. Legacy code integration
4. Frequently occurring problems and solutions
5. Production Patterns
6. Complete example: Payment system

---

1. object adapter

An object adapter wraps an Adaptee using composition. This is the most common and recommended method.

Combination method

#include <iostream>
#include <memory>
#include <string>

class MediaPlayer {
public:
    virtual void play(const std::string& filename) = 0;
    virtual ~MediaPlayer() = default;
};

class VLCPlayer {
public:
    void playVLC(const std::string& filename) {
        std::cout << "Playing VLC: " << filename << '\n';
    }
};

class MP4Player {
public:
    void playMP4(const std::string& filename) {
        std::cout << "Playing MP4: " << filename << '\n';
    }
};

class VLCAdapter : public MediaPlayer {
public:
    VLCAdapter() : vlc(std::make_unique<VLCPlayer>()) {}

    void play(const std::string& filename) override {
        vlc->playVLC(filename);
    }

private:
    std::unique_ptr<VLCPlayer> vlc;
};

class MP4Adapter : public MediaPlayer {
public:
    MP4Adapter() : mp4(std::make_unique<MP4Player>()) {}

    void play(const std::string& filename) override {
        mp4->playMP4(filename);
    }

private:
    std::unique_ptr<MP4Player> mp4;
};

int main() {
    std::unique_ptr<MediaPlayer> player;

    player = std::make_unique<VLCAdapter>();
    player->play("movie.vlc");

    player = std::make_unique<MP4Adapter>();
    player->play("movie.mp4");
}

---

2. class adapter

Class adapters are a way to use multiple inheritance. This is possible in C++, but is less flexible than an object adapter.

Multiple inheritance method

#include <iostream>
#include <string>

class MediaPlayer {
public:
    virtual void play(const std::string& filename) = 0;
    virtual ~MediaPlayer() = default;
};

class VLCPlayer {
public:
    void playVLC(const std::string& filename) {
        std::cout << "Playing VLC: " << filename << '\n';
    }
};

// class adapter (multiple inheritance)
class VLCAdapter : public MediaPlayer, private VLCPlayer {
public:
    void play(const std::string& filename) override {
playVLC(filename);  // call directly
    }
};

int main() {
    MediaPlayer* player = new VLCAdapter();
    player->play("movie.vlc");
    delete player;
}

Advantage: No need to store Adaptee object. Disadvantage: Multiple inheritance, not possible if Adaptee is final.

---

3. Legacy code integration

The Adapter Pattern shines when it comes to integrating legacy systems into a modern codebase. You can use the new interface without modifying existing code.

Old APIs into modern interfaces

#include <iostream>
#include <string>
#include <memory>

// Legacy API (C style)
class LegacyRectangle {
public:
    void draw(int x1, int y1, int x2, int y2) {
        std::cout << "Legacy: Rectangle from (" << x1 << "," << y1
                  << ") to (" << x2 << "," << y2 << ")\n";
    }
};

// modern interface
class Shape {
public:
    virtual void draw() = 0;
    virtual ~Shape() = default;
};

class Rectangle : public Shape {
public:
    Rectangle(int x, int y, int w, int h)
        : x_(x), y_(y), width_(w), height_(h) {}

    void draw() override {
        std::cout << "Modern: Rectangle at (" << x_ << "," << y_
                  << ") size " << width_ << "x" << height_ << '\n';
    }

private:
    int x_, y_, width_, height_;
};

// Adapter
class LegacyRectangleAdapter : public Shape {
public:
    LegacyRectangleAdapter(int x, int y, int w, int h)
        : x_(x), y_(y), width_(w), height_(h),
          legacy(std::make_unique<LegacyRectangle>()) {}

    void draw() override {
        legacy->draw(x_, y_, x_ + width_, y_ + height_);
    }

private:
    int x_, y_, width_, height_;
    std::unique_ptr<LegacyRectangle> legacy;
};

int main() {
    std::unique_ptr<Shape> shape1 = std::make_unique<Rectangle>(10, 20, 100, 50);
    shape1->draw();

    std::unique_ptr<Shape> shape2 = std::make_unique<LegacyRectangleAdapter>(10, 20, 100, 50);
    shape2->draw();
}

---

4. Frequently occurring problems and solutions

Issue 1: Memory leak

Symptom: Memory leak.

Cause: Use of raw pointer.

// ❌ Incorrect use
class Adapter {
Adaptee* adaptee;  // who delete?
};

// ✅ Correct use
class Adapter {
    std::unique_ptr<Adaptee> adaptee;
};

Issue 2: Bi-directional adapter

Symptom: Cyclodependency.

Cause: Convert A to B and B to A.

// ✅ SOLVED: Common interface
class CommonInterface {
    virtual void operation() = 0;
};

class AdapterA : public CommonInterface { /* ... */ };
class AdapterB : public CommonInterface { /* ... */ };

---

5. production pattern

Pattern 1: Combined with Factory

class MediaPlayerFactory {
public:
    static std::unique_ptr<MediaPlayer> create(const std::string& type) {
        if (type == "vlc") {
            return std::make_unique<VLCAdapter>();
        } else if (type == "mp4") {
            return std::make_unique<MP4Adapter>();
        }
        return nullptr;
    }
};

auto player = MediaPlayerFactory::create("vlc");
player->play("movie.vlc");

Pattern 2: Template Adapter

template<typename Adaptee>
class GenericAdapter : public MediaPlayer {
public:
    GenericAdapter() : adaptee(std::make_unique<Adaptee>()) {}

    void play(const std::string& filename) override {
        adaptee->playSpecific(filename);
    }

private:
    std::unique_ptr<Adaptee> adaptee;
};

---

6. Complete example: payment system

#include <iostream>
#include <memory>
#include <string>

class PaymentProcessor {
public:
    virtual bool processPayment(double amount) = 0;
    virtual ~PaymentProcessor() = default;
};

// Legacy PayPal API
class PayPalAPI {
public:
    bool sendPayment(double dollars) {
        std::cout << "PayPal: Processing $" << dollars << '\n';
        return true;
    }
};

// Legacy Stripe API
class StripeAPI {
public:
    bool charge(int cents) {
        std::cout << "Stripe: Charging " << cents << " cents\n";
        return true;
    }
};

// New Square API
class SquareAPI {
public:
    bool makePayment(const std::string& amount) {
        std::cout << "Square: Payment of " << amount << '\n';
        return true;
    }
};

// Adapters
class PayPalAdapter : public PaymentProcessor {
public:
    PayPalAdapter() : paypal(std::make_unique<PayPalAPI>()) {}

    bool processPayment(double amount) override {
        return paypal->sendPayment(amount);
    }

private:
    std::unique_ptr<PayPalAPI> paypal;
};

class StripeAdapter : public PaymentProcessor {
public:
    StripeAdapter() : stripe(std::make_unique<StripeAPI>()) {}

    bool processPayment(double amount) override {
        int cents = static_cast<int>(amount * 100);
        return stripe->charge(cents);
    }

private:
    std::unique_ptr<StripeAPI> stripe;
};

class SquareAdapter : public PaymentProcessor {
public:
    SquareAdapter() : square(std::make_unique<SquareAPI>()) {}

    bool processPayment(double amount) override {
        return square->makePayment("$" + std::to_string(amount));
    }

private:
    std::unique_ptr<SquareAPI> square;
};

class PaymentService {
public:
    PaymentService(std::unique_ptr<PaymentProcessor> processor)
        : processor_(std::move(processor)) {}

    void checkout(double amount) {
        std::cout << "Processing checkout for $" << amount << '\n';
        if (processor_->processPayment(amount)) {
            std::cout << "Payment successful!\n\n";
        } else {
            std::cout << "Payment failed!\n\n";
        }
    }

private:
    std::unique_ptr<PaymentProcessor> processor_;
};

int main() {
    PaymentService service1(std::make_unique<PayPalAdapter>());
    service1.checkout(99.99);

    PaymentService service2(std::make_unique<StripeAdapter>());
    service2.checkout(49.50);

    PaymentService service3(std::make_unique<SquareAdapter>());
    service3.checkout(29.99);
}

---

organize

concept	Description
Adapter Pattern	convert interface
Purpose	Integration of incompatible interfaces
Structure	Target, Adapter, Adaptee
Advantages	Legacy Integration, OCP Compliance, Reusability
Disadvantages	class increment, indirect reference
Use Case	Legacy integrations, third-party libraries, API conversions

Adapter Pattern is an essential pattern to unify incompatible interfaces.

---

FAQ

Q1: When do I use the Adapter Pattern?

A: Used to integrate legacy code, use third-party libraries, and resolve interface inconsistencies.

Q2: Object adapter vs class adapter?

A: Object adapter combination (recommended), Class adapter multiple inheritance (C++ possible).

Q3: What is the difference from Decorator?

A: Adapter focuses on interface conversion, Decorator focuses on feature addition.

Q4: What is the difference from Facade?

A: Adapter focuses on single class transformation, Facade focuses on subsystem simplification.

Q5: What is the performance overhead?

A: 1 indirect reference, negligible.

Q6: What are the Adapter Pattern learning resources?

A:

• “Design Patterns” by Gang of Four
• “Head First Design Patterns” by Freeman & Freeman
• Refactoring Guru: Adapter Pattern

One-Line Summary: The Adapter Pattern allows you to integrate incompatible interfaces. Next, it would be a good idea to read Proxy Pattern.

---
