이 글의 핵심

Practical guide to advanced sorting algorithms. Complete coverage of quick, merge, and heap sort O(n log n) with detailed examples.

Introduction

”The World of O(n log n)”

Advanced sorting achieves O(n log n) using divide and conquer. These are the sorting algorithms used in practice and coding interviews.


1. Quick Sort

Algorithm

Partition around pivot:

[5, 2, 8, 1, 9, 3]
pivot = 5

[2, 1, 3] 5 [8, 9]
   ↓           ↓
[1, 2, 3]   [8, 9]

Python Implementation

Below is a method that divides into three chunks left / equal / right based on pivot, then recursively sorts left and right. Creates new lists, making implementation readable and good for following divide-and-conquer flow.

def quick_sort(arr):
    if len(arr) <= 1:
        return arr

    pivot = arr[len(arr) // 2]
    left = [x for x in arr if x < pivot]
    middle = [x for x in arr if x == pivot]
    right = [x for x in arr if x > pivot]

    return quick_sort(left) + middle + quick_sort(right)

# Test
arr = [5, 2, 8, 1, 9, 3]
print(quick_sort(arr))  # [1, 2, 3, 5, 8, 9]

Step-by-Step Trace:

[5, 2, 8, 1, 9, 3]
pivot=8
left=[5,2,1,3], middle=[8], right=[9]

quick_sort([5,2,1,3]):
  pivot=1
  left=[], middle=[1], right=[5,2,3]

  quick_sort([5,2,3]):
    pivot=2
    left=[], middle=[2], right=[5,3]

    quick_sort([5,3]):
      pivot=3
      left=[], middle=[3], right=[5]
      return [3,5]

    return [2,3,5]

  return [1,2,3,5]

quick_sort([9]):
  return [9]

Final: [1,2,3,5,8,9]

In-Place Implementation

def quick_sort_inplace(arr, low, high):
    if low < high:
        pi = partition(arr, low, high)
        quick_sort_inplace(arr, low, pi - 1)
        quick_sort_inplace(arr, pi + 1, high)

def partition(arr, low, high):
    pivot = arr[high]
    i = low - 1

    for j in range(low, high):
        if arr[j] < pivot:
            i += 1
            arr[i], arr[j] = arr[j], arr[i]

    arr[i + 1], arr[high] = arr[high], arr[i + 1]
    return i + 1

# Usage
arr = [5, 2, 8, 1, 9, 3]
quick_sort_inplace(arr, 0, len(arr) - 1)
print(arr)  # [1, 2, 3, 5, 8, 9]

Partition Trace:

arr = [5, 2, 8, 1, 9, 3], pivot=3

i=-1, j=0: arr[0]=5 (>= 3, skip)
i=-1, j=1: arr[1]=2 (< 3, i++, swap)
  i=0, swap arr[0] and arr[1]: [2, 5, 8, 1, 9, 3]
i=0, j=2: arr[2]=8 (>= 3, skip)
i=0, j=3: arr[3]=1 (< 3, i++, swap)
  i=1, swap arr[1] and arr[3]: [2, 1, 8, 5, 9, 3]
i=1, j=4: arr[4]=9 (>= 3, skip)

Final swap arr[i+1] and arr[high]:
[2, 1, 3, 5, 9, 8]
return i+1=2

Time Complexity

  • Best: O(n log n)
  • Average: O(n log n)
  • Worst: O(n²) (already sorted)
  • Space: O(log n) (recursion stack)
  • Stable: No

2. Merge Sort

Algorithm

Divide → Sort → Merge:

[5, 2, 8, 1]
   ↓ Divide
[5, 2] [8, 1]
   ↓ Divide
[5] [2] [8] [1]
   ↓ Merge
[2, 5] [1, 8]
   ↓ Merge
[1, 2, 5, 8]

Python Implementation

def merge_sort(arr):
    if len(arr) <= 1:
        return arr

    mid = len(arr) // 2
    left = merge_sort(arr[:mid])
    right = merge_sort(arr[mid:])

    return merge(left, right)

def merge(left, right):
    result = []
    i = j = 0

    while i < len(left) and j < len(right):
        if left[i] <= right[j]:
            result.append(left[i])
            i += 1
        else:
            result.append(right[j])
            j += 1

    result.extend(left[i:])
    result.extend(right[j:])
    return result

# Test
arr = [5, 2, 8, 1, 9, 3]
print(merge_sort(arr))  # [1, 2, 3, 5, 8, 9]

Merge Process:

Merge [2, 5] and [1, 8]:

i=0, j=0: left[0]=2, right[0]=1
  1 < 2 → result=[1], j++

i=0, j=1: left[0]=2, right[1]=8
  2 < 8 → result=[1,2], i++

i=1, j=1: left[1]=5, right[1]=8
  5 < 8 → result=[1,2,5], i++

i=2 (end): result.extend([8])
  result=[1,2,5,8]

Time Complexity

  • Best: O(n log n)
  • Average: O(n log n)
  • Worst: O(n log n) (always consistent!)
  • Space: O(n)
  • Stable: Yes

3. Heap Sort

Algorithm

Build max heap → Extract one by one:

def heap_sort(arr):
    import heapq

    # Use min heap
    heap = []
    for num in arr:
        heapq.heappush(heap, num)

    result = []
    while heap:
        result.append(heapq.heappop(heap))

    return result

# Test
arr = [5, 2, 8, 1, 9, 3]
print(heap_sort(arr))  # [1, 2, 3, 5, 8, 9]

In-Place Heap Sort

def heap_sort_inplace(arr):
    """
    In-place heap sort using max heap
    """
    n = len(arr)

    # Build max heap
    for i in range(n // 2 - 1, -1, -1):
        heapify(arr, n, i)

    # Extract elements
    for i in range(n - 1, 0, -1):
        arr[0], arr[i] = arr[i], arr[0]
        heapify(arr, i, 0)

    return arr

def heapify(arr, n, i):
    """
    Heapify subtree rooted at index i
    """
    largest = i
    left = 2 * i + 1
    right = 2 * i + 2

    if left < n and arr[left] > arr[largest]:
        largest = left

    if right < n and arr[right] > arr[largest]:
        largest = right

    if largest != i:
        arr[i], arr[largest] = arr[largest], arr[i]
        heapify(arr, n, largest)

# Test
arr = [5, 2, 8, 1, 9, 3]
print(heap_sort_inplace(arr))  # [1, 2, 3, 5, 8, 9]

Time Complexity

  • Best: O(n log n)
  • Average: O(n log n)
  • Worst: O(n log n)
  • Space: O(1) (in-place possible)
  • Stable: No

4. Sorting Comparison

AlgorithmAverageWorstSpaceStableFeature
QuickO(n log n)O(n²)O(log n)NoFastest
MergeO(n log n)O(n log n)O(n)YesConsistent
HeapO(n log n)O(n log n)O(1)NoIn-place

When to Use Each

# Quick Sort
# - Average case performance critical
# - In-place sorting needed
# - Unstable is acceptable

# Merge Sort
# - Stable sorting required
# - Worst case O(n log n) guaranteed
# - Extra space available

# Heap Sort
# - In-place + O(n log n) guaranteed
# - Don't need stability
# - Priority queue operations

5. Practical Problems

Problem 1: Kth Largest Element

import heapq

def kth_largest(arr, k):
    """
    Kth largest number (O(n log k))
    """
    heap = []

    for num in arr:
        heapq.heappush(heap, num)
        if len(heap) > k:
            heapq.heappop(heap)

    return heap[0]

# Test
arr = [3, 2, 1, 5, 6, 4]
print(kth_largest(arr, 2))  # 5

Using Quick Select (O(n) average):

def quick_select(arr, k):
    """
    Find kth largest using quick select
    Average O(n), worst O(n²)
    """
    if len(arr) == 1:
        return arr[0]

    pivot = arr[len(arr) // 2]
    left = [x for x in arr if x > pivot]
    middle = [x for x in arr if x == pivot]
    right = [x for x in arr if x < pivot]

    if k <= len(left):
        return quick_select(left, k)
    elif k <= len(left) + len(middle):
        return middle[0]
    else:
        return quick_select(right, k - len(left) - len(middle))

# Test
arr = [3, 2, 1, 5, 6, 4]
print(quick_select(arr, 2))  # 5

Problem 2: Merge Sorted Arrays

def merge_sorted_arrays(arr1, arr2):
    """
    Merge two sorted arrays (O(n+m))
    """
    result = []
    i = j = 0

    while i < len(arr1) and j < len(arr2):
        if arr1[i] < arr2[j]:
            result.append(arr1[i])
            i += 1
        else:
            result.append(arr2[j])
            j += 1

    result.extend(arr1[i:])
    result.extend(arr2[j:])
    return result

# Test
arr1 = [1, 3, 5]
arr2 = [2, 4, 6]
print(merge_sorted_arrays(arr1, arr2))
# [1, 2, 3, 4, 5, 6]

6. Practical Tips

Coding Interview Tips

# ✅ Use built-in sort most of the time
arr.sort()  # O(n log n)

# ✅ Understand time complexity
# - Quick: Average O(n log n), worst O(n²)
# - Merge: Always O(n log n)
# - Heap: Always O(n log n), in-place

# ✅ Know stability
# - Stable: Merge, Timsort
# - Unstable: Quick, Heap

# ✅ Space considerations
# - In-place: Quick, Heap
# - Extra space: Merge

Common Mistakes

# ❌ Wrong: Quick sort on already sorted
arr = [1, 2, 3, 4, 5]
quick_sort(arr)  # O(n²) worst case!

# ✅ Better: Use merge or built-in
arr.sort()  # Timsort handles this well

# ❌ Wrong: Forgot base case
def quick_sort(arr):
    pivot = arr[0]  # Error if arr is empty!
    # ...

# ✅ Correct: Check base case
def quick_sort(arr):
    if len(arr) <= 1:
        return arr
    # ...

Advanced Example: Stable Sort with Keys

When same scores must preserve original input order, need stable sort like insertion, merge, or Timsort.

from dataclasses import dataclass

@dataclass
class Row:
    name: str
    score: int

rows = [
    Row("A", 90),
    Row("B", 90),
    Row("C", 80),
]

# Python's sort is stable, use index as secondary key
indexed = list(enumerate(rows))
indexed.sort(key=lambda t: (-t[1].score, t[0]))
ordered = [r for _, r in indexed]
print([r.name for r in ordered])  # ['A', 'B', 'C']

Cautions

  • Partial sorting (top-k) may be more efficient with heap or heapq.nsmallest.
  • For nearly sorted arrays, insertion sort or Timsort approaches best case.

In Practice

  • In application code, use language built-in sorting and only define custom keys.
  • For large-scale data, consider external sorting (disk, chunks) and distributed frameworks.

Comparison and Alternatives

SituationRecommendation
General list sortinglist.sort / sorted
Top-kHeap
Uniform integer distributionCounting sort (separate article)

Additional Resources


Summary

Key Points

  1. Quick: Pivot partition, average O(n log n), unstable
  2. Merge: Divide and merge, always O(n log n), stable
  3. Heap: Heap structure, O(n log n), in-place
  4. Practice: Python Timsort, C++ Introsort

Algorithm Selection

NeedAlgorithm
Fastest averageQuick
Guaranteed O(n log n)Merge or Heap
StableMerge
In-placeQuick or Heap
Nearly sortedInsertion or Timsort
